Home > Professional Curtain Wall Window Manufacturer > Curtain Wall Window Project > Curtain Wall Window Series // Zenith 65 Series Exposed Frame Curtain Wall
  • Curtain Wall Window Series // Zenith 65 Series Exposed Frame Curtain Wall / Australian Standard,Juheintl,Curtain Wall Window Series // Zenith 65 Series Exposed Frame Curtain Wall
  • Curtain Wall Window Series // Zenith 65 Series Exposed Frame Curtain Wall / Australian Standard,Juheintl,Curtain Wall Window Series // Zenith 65 Series Exposed Frame Curtain Wall

Curtain Wall Window Series // Zenith 65 Series Exposed Frame Curtain Wall / Australian Standard

Conventional component curtain wall, the first choice for cross-floor living room exterior windows with optional exposed, hidden and semi-hidden frames, perfectly applied to villa halls.
Air Tightness
Level 6
Water Tightness
Level 8
Wind Pressure Resistance
Level 10
Thermal Insulation
1.5 W/(㎡·K)
Sound Insulation
42db
GET A QUOTE
Add to Quote List View Quote List
  • Curtain Wall Window Series // Zenith 65 Series Exposed Frame Curtain Wall / Australian Standard,Juheintl,Curtain Wall Window Series // Zenith 65 Series Exposed Frame Curtain Wall

  • Description

  • Key Features

  • Typical Node Diagram

  • Project Application

Product Advantages
  1. Conventional stick-built curtain wall
  2. Ideal choice for exterior windows in double-height living rooms
  3. Available options: exposed frame, hidden frame, horizontally exposed/vertically hidden, and vertically exposed/horizontally hidden configurations



Parameter Specification
Insulation Strip —
Profile Thickness 3.0mm
Frame Visual Surface 65mm
Visible Surface of Mullion Outdoor: 65mm / Indoor: 65mm
Fan Visual Surface Indoor: Frame 40mm, Sash 13mm
Glass Specifications (Frame, Sash) 6mm Clear Glass + 12Ar + 6mm Clear Glass
Accessories Brand —
Window Screen Scheme and Mesh Type —
Available Colors Sand Gray, Sand Brown, Starry Sky Gray, Star Black
Usage Scenario Villa Lobby
Notes —

Unitized Hidden-Frame High-End Curtain Wall Series

The maximum single unit height reaches 6800mm, with a unit panel width up to 1800mm. The overall facade can be designed in unlimited continuous width.All products adopt factory standardized production and prefabricated assembly construction to ensure stable and reliable quality.Both electric and manual opening modes are available for selection.
About US
Juheintl

Curtain wall window

What curtain wall and window systems do you mainly offer? And which buildings are they suitable for?

We mainly specialize in traditional stick curtain wall, unitized curtain wall, SSG (Structural Silicone Glazing) curtain wall, slim-frame panoramic curtain wall, and lift-and-slide door curtain wall systems. Our products are applicable to residential buildings, hotels, office buildings, commercial complexes and other low-rise, mid-rise and high-rise projects, which can meet different architectural needs such as energy saving, sound insulation, waterproofing and wind pressure resistance.

What performance standards can your products meet? Do you have any certifications?

Our curtain wall and window systems strictly comply with GB (Chinese National Standard), ASTM (American Standard) and EN (European Standard). We can provide:
  • Test reports on water tightness, air tightness and wind pressure resistance
  • Sound insulation, heat insulation (U-value) and energy-saving parameters
  • Support for export certifications such asCE, ASTM and CSA
All profiles, glass, hardware and gaskets adopt national standard/brand accessories with stable and reliable quality.

Are you a factory or a trading company? What is your production capacity?

We are a source factory based in Foshan, with our own extrusion, spraying, deep processing and assembly production lines. We support OEM/ODM customization, with stable monthly production capacity, and can undertake bulk export orders, engineering projects and mass orders. We independently control the entire process from design, deepening, production to delivery.

Can you provide detailed drawings, node drawings, BIM/3D models?

Yes, we can provide:
  • Curtain wall and window node drawings, section drawings and detail drawings
  • 3D renderings and product models
  • BIM models, CAD drawings and technical parameter sheets
We support cooperating with design institutes, general contractors and owners to complete drawing confirmation and technical disclosure.

What is the installation of curtain walls and windows complicated? Do you provide installation guidance?

Our systems are standardized in design and easy to install. Meanwhile, we provide:
  • Detailed installation manuals, node diagrams and video guidance
  • On-site technical support for large-scale projects
  • Full docking to solve problems such as waterproofing, closing and commissioning during installation
We ensure installation efficiency and project quality.

What is the lead time for orders? How about the packaging and export process?

- Regular orders: 15–25 days (depending on quantity and drawing complexity)
- Packaging: Export-standard plywood wooden cases + protective film + corner protectors, suitable for sea/land transportation
- We can provide a full set of export documents such as packing list, commercial invoice and bill of lading, and support trade terms such as FOB and CIF.

What about after-sales service and quality guarantee?

All products go through multiple quality inspections before leaving the factory to ensure defect-free delivery.
- We provide quality guarantee service under normal use conditions.
- Our after-sales team responds quickly, providing technical solutions, accessory replacement and problem troubleshooting.
- Long-term cooperative projects can enjoy priority scheduling and exclusive technical docking.
